M 400 Pick and Carry Compact crawler crane

M400

COMPACT CRAWLER CRANE

Pick and Carry

M 400 is not only an amazing compact crawler crane, but also a tireless Pick & Carry Crane able to moves with millimetric precision in very narrow spaces and raising up to 1,6 Ton.
Two cranes in one and more: the innovative technology of the double cross beam outriggers confer to the crane greater positioning chance, thus facilitating the use in operating situations considered for a long time impossible. The dimensions and lightweight, combined to millimetric precision maneuverability, reduce enormously the operating time increasing the quality guaranteeing the total safety.

Dimensions ( h × w × l )

1,96 × 1,20 × 4,25 m

Weight (excluding accesories)

4300 kg

Lifting capacity

4000 kg

Maximum outreach with hydraulic Jib (optional)

17,00 m

Maximum lifting height with hydraulic Jib (from the ground)

21,10 m

Maximum lifting height (underground-winch)

-53,5 m

Technology

Every function under control The multifunction proportional radio control provided with an integrated control display, permits as well to verify in real time all the parameters of the machine.

Smart Stability Control The integrated control system allows the crane to automatically adapt its load capacity according to the position of each outriggers calculating for every single position the optimal performance.

No limits rotation Easy to operate, around and over obstacles, thanks to the ”ballast free” boom.

Always Ready to Work The “X” configuration allows to operate with narrow outriggers and minimum obstruction.

Easy To Drive The Machine can level and operate on steep grounds.

Jib Over Line +15° Jib to overtake beyond obstacles

Jib Ready to use Always “Ready to operate” folded hydraulic jib under the main boom.

Bi-Energy Plug-In Double power supply system. Diesel engine and electric engine powered by a Plug-In Lithium battery.

Dimensions

Technical specifications

	Max capacity	4000 Kg / 2 m
	Max outreach	12,10 m
	Max outreach with Jib (optional)	17,00 m
	Max hook height	14,80 m
	Max outreach with Jib (optional)	21,10 m
	Slewing angle / Rotation speed	Continuous / 1 rpm
	Winch (optional)	First layer pull: 1000 Kg Rope lengh: 60 m Speed in direct pull: 47 m / min
	Radio remote control	Scanreco Can-Bus + Display
	Stability control	Electronic
	Stability system	Max 4490×4570
	Weights	Standard crane: 4300 Kg Jib : 230 Kg Electric motor: 40 kg Winch: 65 kg Mobile ballast (Pick & Carry): 300 kg
	Crawler Crane Traction	Trasmission: Moto-reducer Scope: 55 l/min Pressure: 200 Bar Speed: 0 – 2 Km/h Max slope degree: 25° Max pressure on the ground: 0,41 Kg/cm²
	Thermal Engine	Max power: 18.9 kw – 25.7 Hp Max torque: 64 Nm Tank capacity: 25 l
	Electric Engine	Electric Engine Power supply: 400 V Power: 5,5 Kw Electric engine with lithium battery Power supply: 48 V Battery capacity: 200 Ah Power: 8,5 W – 12 Hp

Loading tables

Request further information

Standard equipment

Radio remote control with LCD display for crawler, chassis and crane function
Continuous rotation
Predisposition for winch installation
Predisposition for Jib installation
Outriggers continuous variations control system
Automatic stabilization
Two speed crawler translation
Manual endothermic engine rpm increment
N° 4 lifting connections
Electronic Limiting Device
Auto diagnostic
According to EN13000
BG Connect
Smart Stability Control (SSC)

Optional

1000 Kg hydraulic winch
Lowered hook connections
Fourth, third line pull pulleys
Plates for outriggers
Working LED light on the main boom
Working LED light on the Jib
N° 4 Working LED lights on the crawler
Hydraulic Jib with opening up to 195°
Three phases electric engine 5,5 kW/400 V
Automatic endothermic engine rpm increment
No marking rubber pads
Two man baskets capacity CE
LED lights for outriggers
Green oil
Automatic closing
Electric engine with lithium battery
